Hotel Management System In Visual Basic.Net And MySQL Database With Source Code
in this visual basic .net project tutorial we will see how to create a simple desktop application with winforms to manage hotel reservations using vb.net programming language and mysql database.
goals of this project:
- give students / curious persons an example so they can learn from.- give beginners a step by step project so they can create their own.
- help people to learn vb.net by making projects.
- sharing knowledge with others.
tools:
- visual basic .net programming language.
- visual studio express 2013.
- mysql database.
- xampp server.
- phpmyadmin.
- xampp server.
- phpmyadmin.
Watch The Full Project Tutorial
if you want the source code click on the download button below
in this project we will create 4 classes and 4 forms:
- classes:
* CONNECTION > create the connection with mysql database.
* ClIENT > where we will add functions for the client.
* ROOMS > where we will add functions for the room.
* RESERVATIONS > where we will add functions for the reservation.
- forms:
* Login > where the user can enter his username to login.
* Manage Clients > where we will manage the hotel client informations.
* Manage Rooms > where we will mange the hotel's rooms.
* Manage Reservations > where we will add functions for the reservation.
> and you need to download mysql connector from here -> https://dev.mysql.com/downloads/connector/net/8.0.html
1 - The Login Form
before getting access to the main form the user need to login first by entering his username and password.
and we will check if the username/password textbox are empty.and if the user enter the wrong username or password or this user doesn't exists at all.
The Login Button:
Private Sub ButtonLogin_Click(sender As Object, e As EventArgs) Handles ButtonLogin.ClickDim connection As New CONNECTION()
Dim adapter As New MySqlDataAdapter()
Dim command As New MySqlCommand()
Dim table As New DataTable()
Dim username As String = TextBoxUsername.Text
Dim password As String = TextBoxPassword.Text
Dim selectQuery As String = "SELECT * FROM `users` WHERE `username`=@un AND `password`=@pass"
command.CommandText = selectQuery
command.Connection = connection.getConnection()
command.Parameters.Add("@un", MySqlDbType.VarChar).Value = username
command.Parameters.Add("@pass", MySqlDbType.VarChar).Value = password
adapter.SelectCommand = command
adapter.Fill(table)
If table.Rows.Count > 0 Then
Dim mainForm As New MainForm()
mainForm.Show()
Me.Hide()
Else
MessageBox.Show("Invalid Username Or Password", "Login Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End Sub
if the user enter the correct username and password we will show him the main form.
2 - The Main Form
this is a quick and easy from with a menu created with a panel and labels to take the user to the selected form on label click.
Private Sub LabelMClients_Click(sender As Object, e As EventArgs) Handles LabelMClients.Click
Dim manage_Cl_Form As New ManageClientsForm()
manage_Cl_Form.ShowDialog()
End Sub
Private Sub LabelMRooms_Click(sender As Object, e As EventArgs) Handles LabelMRooms.Click
Dim manage_Rm_Form As New ManageRoomsForm()
manage_Rm_Form.ShowDialog()
End Sub
Private Sub LabelMReservastions_Click(sender As Object, e As EventArgs) Handles LabelMReservastions.Click
Dim manage_Rv_Form As New ManageReservationsForm()
manage_Rv_Form.ShowDialog()
End Sub
3 - The Manage Hotel Clients Form
this form allow the user to manage the hotel clients.
this form contains a datagridview filled with all clients data.
this form call functions from the class "CLIENT".
Private Sub ButtonAdd_Click(sender As Object, e As EventArgs) Handles ButtonAdd.Click
Dim fname As String = TextBoxFname.Text
Dim lname As String = TextBoxLname.Text
Dim phone As String = TextBoxPhone.Text
Dim email As String = TextBoxEmail.Text
If fname.Trim().Equals("") Or lname.Trim().Equals("") Or phone.Trim().Equals("") Then
MessageBox.Show("Required First & Last Name, Phone", "Missing Information", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
If client.addClient(fname, lname, phone, email) Then
MessageBox.Show("New Client Added Successfully", "Add Client", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = client.getAllClients()
Else
MessageBox.Show("Client Not Added", "Add Client", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End If
End If
End Sub
- Edit The Selected Client Button
Private Sub ButtonEdit_Click(sender As Object, e As EventArgs) Handles ButtonEdit.Click
Dim fname As String = TextBoxFname.Text
Dim lname As String = TextBoxLname.Text
Dim phone As String = TextBoxPhone.Text
Dim email As String = TextBoxEmail.Text
If TextBoxId.Text.Trim().Equals("") Then
MessageBox.Show("Select The User You Want to Edit", "Missing ID", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
If fname.Trim().Equals("") Or lname.Trim().Equals("") Or phone.Trim().Equals("") Then
MessageBox.Show("Required First & Last Name, Phone", "Missing Information", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim id As Integer = Convert.ToInt32(TextBoxId.Text)
If client.editClient(id, fname, lname, phone, email) Then
MessageBox.Show("Client Updated Successfully", "Edit Client", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = client.getAllClients()
Else
MessageBox.Show("Client Not Updated", "Edit Client", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End If
End If
End If
End Sub
- Delete The Selected Client Button
Private Sub ButtonRemove_Click(sender As Object, e As EventArgs) Handles ButtonRemove.Click
If TextBoxId.Text.Trim().Equals("") Then
MessageBox.Show("Enter The Client Id", "Missing ID", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim id As Integer = Convert.ToInt32(TextBoxId.Text)
If client.removeClient(id) Then
MessageBox.Show("Client Deleted Successfully", "Delte Client", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = client.getAllClients()
' clear boxes
TextBoxId.Text = ""
TextBoxFname.Text = ""
TextBoxLname.Text = ""
TextBoxPhone.Text = ""
TextBoxEmail.Text = ""
Else
MessageBox.Show("Client Not Deleted", "Delete Client", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End If
End If
End Sub
If TextBoxId.Text.Trim().Equals("") Then
MessageBox.Show("Enter The Client Id", "Missing ID", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim id As Integer = Convert.ToInt32(TextBoxId.Text)
If client.removeClient(id) Then
MessageBox.Show("Client Deleted Successfully", "Delte Client", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = client.getAllClients()
' clear boxes
TextBoxId.Text = ""
TextBoxFname.Text = ""
TextBoxLname.Text = ""
TextBoxPhone.Text = ""
TextBoxEmail.Text = ""
Else
MessageBox.Show("Client Not Deleted", "Delete Client", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End If
End If
End Sub
4 - The Manage Hotel Rooms Form
here the user can add a new room to the hotel system.
when you add a new room you need to select the type of room (single, double, family, suite).
and like the client form you can view all rooms in a datagridview + how many rooms this hotel have, and add, edit, remove the selecte one + a combobx populated with all room's categories.
- Add New Room Button
when you add a new room the "reserved" column will be set to no by default.
Private Sub ButtonAdd_Click(sender As Object, e As EventArgs) Handles ButtonAdd.Click
Try
Dim type As Integer = Convert.ToInt32(ComboBoxType.SelectedValue)
Dim phone As String = TextBoxPhone.Text
Dim reserved As String = ""
If RadioButtonYes.Checked Then
reserved = "Yes"
ElseIf RadioButtonNo.Checked Then
reserved = "No"
End If
If TextBoxNumber.Text.Trim().Equals("") Or TextBoxPhone.Text.Trim().Equals("") Then
MessageBox.Show("Make Sure to Enter The Room Number and The Phone Number", "Empty Fields", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim number As Integer = Convert.ToInt32(TextBoxNumber.Text)
If room.addRoom(number, type, phone, reserved) Then
MessageBox.Show("Room Added Successfully", "Add Room", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = room.getAllRooms()
' display the number of rooms on the LabelRoomsCount
LabelRoomsCount.Text = room.getAllRooms().Rows.Count.ToString() + " Room"
Else
MessageBox.Show("Room Not Added", "Add Room", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Duplicate Room Number", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End Try
End Sub
Try
Dim type As Integer = Convert.ToInt32(ComboBoxType.SelectedValue)
Dim phone As String = TextBoxPhone.Text
Dim reserved As String = ""
If RadioButtonYes.Checked Then
reserved = "Yes"
ElseIf RadioButtonNo.Checked Then
reserved = "No"
End If
If TextBoxNumber.Text.Trim().Equals("") Or TextBoxPhone.Text.Trim().Equals("") Then
MessageBox.Show("Make Sure to Enter The Room Number and The Phone Number", "Empty Fields", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim number As Integer = Convert.ToInt32(TextBoxNumber.Text)
If room.addRoom(number, type, phone, reserved) Then
MessageBox.Show("Room Added Successfully", "Add Room", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = room.getAllRooms()
' display the number of rooms on the LabelRoomsCount
LabelRoomsCount.Text = room.getAllRooms().Rows.Count.ToString() + " Room"
Else
MessageBox.Show("Room Not Added", "Add Room", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Duplicate Room Number", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End Try
End Sub
- Edit The Selected Room Button
Private Sub ButtonEdit_Click(sender As Object, e As EventArgs) Handles ButtonEdit.Click
Try
Dim type As Integer = Convert.ToInt32(ComboBoxType.SelectedValue)
Dim phone As String = TextBoxPhone.Text
Dim reserved As String = ""
If RadioButtonYes.Checked Then
reserved = "Yes"
ElseIf RadioButtonNo.Checked Then
reserved = "No"
End If
If TextBoxNumber.Text.Trim().Equals("") Or TextBoxPhone.Text.Trim().Equals("") Then
MessageBox.Show("Make Sure to Enter The Room Number and The Phone Number", "Empty Fields", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim number As Integer = Convert.ToInt32(TextBoxNumber.Text)
If room.editRoom(number, type, phone, reserved) Then
MessageBox.Show("Room Updated Successfully", "Edit Room", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = room.getAllRooms()
Else
MessageBox.Show("Room Not Updated", "Edit Room", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message)
End Try
End Sub
Try
Dim type As Integer = Convert.ToInt32(ComboBoxType.SelectedValue)
Dim phone As String = TextBoxPhone.Text
Dim reserved As String = ""
If RadioButtonYes.Checked Then
reserved = "Yes"
ElseIf RadioButtonNo.Checked Then
reserved = "No"
End If
If TextBoxNumber.Text.Trim().Equals("") Or TextBoxPhone.Text.Trim().Equals("") Then
MessageBox.Show("Make Sure to Enter The Room Number and The Phone Number", "Empty Fields", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
Dim number As Integer = Convert.ToInt32(TextBoxNumber.Text)
If room.editRoom(number, type, phone, reserved) Then
MessageBox.Show("Room Updated Successfully", "Edit Room", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = room.getAllRooms()
Else
MessageBox.Show("Room Not Updated", "Edit Room", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message)
End Try
End Sub
- Delete The Selected Room Button
Private Sub ButtonRemove_Click(sender As Object, e As EventArgs) Handles ButtonRemove.Click
Try
Dim number As Integer = Convert.ToInt32(TextBoxNumber.Text)
If room.removeRoom(number) Then
MessageBox.Show("Room Deleted Successfully", "Delete Room", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = room.getAllRooms()
' reset and clear fields
TextBoxNumber.Text = ""
ComboBoxType.SelectedIndex = 0
TextBoxPhone.Text = ""
RadioButtonYes.Checked = True
' display the number of rooms on the LabelRoomsCount
LabelRoomsCount.Text = room.getAllRooms().Rows.Count.ToString() + " Room"
Else
MessageBox.Show("Room Not Deleted", "Delete Room", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End If
Catch ex As Exception
MessageBox.Show(ex.Message)
End Try
End Sub
Try
Dim number As Integer = Convert.ToInt32(TextBoxNumber.Text)
If room.removeRoom(number) Then
MessageBox.Show("Room Deleted Successfully", "Delete Room", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = room.getAllRooms()
' reset and clear fields
TextBoxNumber.Text = ""
ComboBoxType.SelectedIndex = 0
TextBoxPhone.Text = ""
RadioButtonYes.Checked = True
' display the number of rooms on the LabelRoomsCount
LabelRoomsCount.Text = room.getAllRooms().Rows.Count.ToString() + " Room"
Else
MessageBox.Show("Room Not Deleted", "Delete Room", MessageBoxButtons.OK, MessageBoxIcon.Warning)
End If
Catch ex As Exception
MessageBox.Show(ex.Message)
End Try
End Sub
5 - The Manage Hotel Reservations Form
This form allow the user to manage the clients room reservations.
to create a reservation you need: 1) enter the reservation id, 2) select the client who will reserve, 3) you need to select the room where the client will stay.
when you add a new reservation the system will check:
- if the user enter all required informations.
- if the user enter a date in that is equal or come after the current day date.
- if the user enter a date out that is equal or come after the date in.
- Add a New Reservation Button
Private Sub ButtonAdd_Click(sender As Object, e As EventArgs) Handles ButtonAdd.Click
Try
Dim clientId As Integer = Convert.ToInt32(TextBoxClientID.Text)
Dim roomNumber As Integer = Convert.ToInt32(ComboBoxRoomNumber.SelectedValue.ToString())
Dim dateIn As Date = DateTimePickerIN.Value
Dim dateOut As Date = DateTimePickerOUT.Value
If DateTime.Compare(dateIn.Date, DateTime.Now.Date) < 0 Then
MessageBox.Show("The Date In Must be = Or > to Today Date", "Invalid Date IN", MessageBoxButtons.OK, MessageBoxIcon.Error)
ElseIf DateTime.Compare(dateOut.Date, dateIn.Date) < 0 Then
MessageBox.Show("The Date Out Must be = Or > to The Date In", "Invalid Date OUT", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
If reservation.addReservation(roomNumber, clientId, dateIn, dateOut) Then
MessageBox.Show("Reservation Added Successfully", "Add Reservation", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = reservation.getAllReservations()
' we need to refresh the combobox to show only the not reserved rooms
ComboBoxType.DataSource = room.getAllRoomsType()
Else
MessageBox.Show("Reservation NOT Added", "Add Reservation", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Add Reservation Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End Try
End Sub
Try
Dim clientId As Integer = Convert.ToInt32(TextBoxClientID.Text)
Dim roomNumber As Integer = Convert.ToInt32(ComboBoxRoomNumber.SelectedValue.ToString())
Dim dateIn As Date = DateTimePickerIN.Value
Dim dateOut As Date = DateTimePickerOUT.Value
If DateTime.Compare(dateIn.Date, DateTime.Now.Date) < 0 Then
MessageBox.Show("The Date In Must be = Or > to Today Date", "Invalid Date IN", MessageBoxButtons.OK, MessageBoxIcon.Error)
ElseIf DateTime.Compare(dateOut.Date, dateIn.Date) < 0 Then
MessageBox.Show("The Date Out Must be = Or > to The Date In", "Invalid Date OUT", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
If reservation.addReservation(roomNumber, clientId, dateIn, dateOut) Then
MessageBox.Show("Reservation Added Successfully", "Add Reservation", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = reservation.getAllReservations()
' we need to refresh the combobox to show only the not reserved rooms
ComboBoxType.DataSource = room.getAllRoomsType()
Else
MessageBox.Show("Reservation NOT Added", "Add Reservation", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Add Reservation Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End Try
End Sub
- Edit The Selected Reservation Button
Private Sub ButtonEdit_Click(sender As Object, e As EventArgs) Handles ButtonEdit.Click
Try
Dim reservationId As Integer = Convert.ToInt32(TextBoxReservationID.Text)
Dim clientId As Integer = Convert.ToInt32(TextBoxClientID.Text)
Dim roomNumber As Integer = Convert.ToInt32(DataGridView1.CurrentRow.Cells(2).Value.ToString())
Dim dateIn As Date = DateTimePickerIN.Value
Dim dateOut As Date = DateTimePickerOUT.Value
If DateTime.Compare(dateIn.Date, DateTime.Now.Date) < 0 Then
MessageBox.Show("The Date In Must be = Or > to Today Date", "Invalid Date IN", MessageBoxButtons.OK, MessageBoxIcon.Error)
ElseIf DateTime.Compare(dateOut.Date, dateIn.Date) < 0 Then
MessageBox.Show("The Date Out Must be = Or > to The Date In", "Invalid Date OUT", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
If reservation.editReservation(reservationId, roomNumber, clientId, dateIn, dateOut) Then
MessageBox.Show("Reservation Updated Successfully", "Edit Reservation", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = reservation.getAllReservations()
Else
MessageBox.Show("Reservation NOT Updated", "Edit Reservation", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Edit Reservation Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End Try
End Sub
Try
Dim reservationId As Integer = Convert.ToInt32(TextBoxReservationID.Text)
Dim clientId As Integer = Convert.ToInt32(TextBoxClientID.Text)
Dim roomNumber As Integer = Convert.ToInt32(DataGridView1.CurrentRow.Cells(2).Value.ToString())
Dim dateIn As Date = DateTimePickerIN.Value
Dim dateOut As Date = DateTimePickerOUT.Value
If DateTime.Compare(dateIn.Date, DateTime.Now.Date) < 0 Then
MessageBox.Show("The Date In Must be = Or > to Today Date", "Invalid Date IN", MessageBoxButtons.OK, MessageBoxIcon.Error)
ElseIf DateTime.Compare(dateOut.Date, dateIn.Date) < 0 Then
MessageBox.Show("The Date Out Must be = Or > to The Date In", "Invalid Date OUT", MessageBoxButtons.OK, MessageBoxIcon.Error)
Else
If reservation.editReservation(reservationId, roomNumber, clientId, dateIn, dateOut) Then
MessageBox.Show("Reservation Updated Successfully", "Edit Reservation", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = reservation.getAllReservations()
Else
MessageBox.Show("Reservation NOT Updated", "Edit Reservation", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Edit Reservation Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End Try
End Sub
- Remove The Selected Reservation Button
Private Sub ButtonRemove_Click(sender As Object, e As EventArgs) Handles ButtonRemove.Click
Try
Dim reservationId As Integer = Convert.ToInt32(TextBoxReservationID.Text)
Dim roomNumber As Integer = Convert.ToInt32(DataGridView1.CurrentRow.Cells(2).Value.ToString())
If reservation.removeReservation(reservationId, roomNumber) Then
MessageBox.Show("Reservation Deleted Successfully", "Remove Reservation", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = reservation.getAllReservations()
Else
MessageBox.Show("Reservation NOT Deleted", "Remove Reservation", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Remove Reservation Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End Try
End Sub
Try
Dim reservationId As Integer = Convert.ToInt32(TextBoxReservationID.Text)
Dim roomNumber As Integer = Convert.ToInt32(DataGridView1.CurrentRow.Cells(2).Value.ToString())
If reservation.removeReservation(reservationId, roomNumber) Then
MessageBox.Show("Reservation Deleted Successfully", "Remove Reservation", MessageBoxButtons.OK, MessageBoxIcon.Information)
DataGridView1.DataSource = reservation.getAllReservations()
Else
MessageBox.Show("Reservation NOT Deleted", "Remove Reservation", MessageBoxButtons.OK, MessageBoxIcon.Error)
End If
Catch ex As Exception
MessageBox.Show(ex.Message, "Remove Reservation Error", MessageBoxButtons.OK, MessageBoxIcon.Error)
End Try
End Sub
if you want the source code click on the download button below
Delivery: Instant Source Code Download.
More VB.NET Projects:
- VB.Net Inventory System Source Code
- VB.Net Students Management System Source Code
